VERTICAL METAL BAND SAW
VERTICAL METAL BAND SAW
Machinery, Micro-tec, Vertical Metal Band Saws Delivery Available | Harare | Mutare | BulawayoVMBS 1408
Vertical metal cutting
Vertical metal band
saws Metal Kraft
Technical specifications
| Throat | 356 mm |
| Max. cutting height | 205 mm |
| table size | 500 x 500 mm |
| working height | 990 mm |
| Table swivel area left / right | |
| Table swivel area front / rear | |
| saw band | 2880 mm |
| Max. saw band width | 13 mm |
| Saw blade speed (1st gear) | 20 – 80 m / min |
| Sägebandschweißgeräteleistung | 13 mm |
| engine power | 0.75 kW |
| Dimensions | 850 x 600 x 1740 mm |
| mass | 275 kg |
| Wheel-Ø | 368 mm |
| SPL | 64.9 dB (A) |
| Table load max. | 150 kg |
description
In solid and proven construction with band welding unit
- Extremely stable construction, entire machine body made of steel
- User-friendly operating concept
- With workplace lighting
- Tilting work table made of gray cast iron
- Speed continuously adjustable
- Tape tension and tape speed indicator
- Blower for sawdust
- Integrated band welding unit with annealing, cutting and grinding device
- With rip fence
ON ORDER ONLY
